I. System Overview:

        With the deepening of enterprise reform in China and the continuous expansion of security projects, monitoring systems have become an indispensable part of and prevention for various enterprises and public places. Coupled with the rapid development of computer networks, security system equipment can now be remotely controlled through network technology. Network control is further divided into Wide Area Network (WAN) control and Local Area Network (LAN) control. Within the scope of a LAN, the KVM extender application solution makes remote multi-point control simpler more convenient.

KVM Extender Remote Multi-point Control Application Solution in Surveillance Systems

II. Design Principles:

       User-Centric Principle: solution aims to meet user needs, maximize the satisfaction of functional requirements proposed by users, and ensure practicality based on the characteristics of the center.

Strong Security: Secure placement of equipment avoid loss and damage, extending the service life of the host.

       Environment Improvement: Save space, reduce noise and heat, avoid host radiation, and create a quiet, spacious, elegant, comfortable operating environment.

Integrability and Scalability: Fully consider the decentralized control of the systems involved; ensure the advancedness and rationality of the overall structure, which possesses scalability and compatibility allowing the integration of advanced products of different types from different manufacturers, so that the entire system can be continuously enriched and improved with technological development and progress.

System Operability and Sim: The system design must ensure the operability of specific functions, with a reasonable interface layout and intuitive, simple operation procedures, requiring no drivers, plug-and-play, simple installation and easy to, overall reflecting the system's simplicity and practicality.

III. Products Used: Yanyu 120m HDMI KVM Extender

KVM Extender Remote Multi-point Application Solution in Surveillance Systems

Product Parameters

Product Name: HDMI KVM Extender

Housing Material: Aluminum alloy housing

Protection and Anti-interference: Lightning protection, anti-static anti-interference

Driver Support: Driverless, plug and play

Transmission Characteristics: Real-time transmission, zero latency

Maximum Distance: 120 meters via a single network, capable of extending the distance between the device and the host using a single Cat5e or Cat6 network cable

Compatibility: Supports HDMI signal and KVM mouse/keyboard signal extensionTransmission Medium: Uses Cat5e or Cat6 twisted-pair cables for transmission, easy installation

Power Supply Method: Flexible power supply, device-side power supply option available

IV. System Functions:

1. Image Quality: The monitoring image is extended to the remote end via the KVM extender (120m HD HDMI KVM Extender MT120HK) using a network cable. The video image is clear with no significant attenuation, and operation is lag-free.

2. Multi-point Operation: Operation be performed both in the server room and at multiple remote control points, with all screens displaying synchronously.

V. System Composition and Detailed Introduction:

Main Control System: Digital video, camera, monitor, etc.

Extension Device: KVM extender (120m HD HDMI KVM Extender MT-120HK) and network cable.

System Structure Diagram:

KVM extender remote multi-point control application solution in monitoring systems

        No additional control hosts or any network devices need to be added at the remote points, and the operating terminal only requires a keyboard, mouse, and monitor. KVM extenders consist of a transmitter and a receiver for one-to-one control operations; to one-to-many control, multiple sets of KVM extenders can be cascaded. KVM extenders have KVM output interfaces at both the local and remote ends. corresponding interface on the host is occupied by the first set of extenders, but the transmitter's output interface is restored, so the second set can be connected to the KVM interface of the first set's transmitter, and the third set can use the KVM output interface of the second set's transmitter as the signal source. If the number of control points needs to be further expanded, a VGA splitter and a USB hub can be added to the DVR to expand the VGA and USB interfaces, making this system easy to expand.
