Portable 17.3-inch 4-Port KVM Console

| Product Features:

1. All-in-One Portable Design

Integrates a 17.3-inch LED screen, a 104-key ultra-slim silent keyboard, a touchpad, and a 4-port KVM switch into a single unit. Its all-in-one design makes it easy to transport and suitable for a wide range of operations and maintenance environments.

2. 4-Port Switching · Multi-Device Management

Supports simultaneous connection to 4 computers, servers, or industrial PCs. Quickly switch between devices via the KVM OSD menu, hotkeys, or physical buttons for higher O&M efficiency.

3. Full HD Display Quality

With a 1920×1080@60Hz HD resolution, 300 nits brightness, 700:1 contrast ratio, and a 16:9 widescreen aspect ratio, the display delivers clear and detailed images, ideal for extended O&M use.

4. Intelligent Switching Management

￮ Supports three switching methods: OSD menu, panel buttons, and customizable hotkeys

￮ Automatically saves the keyboard’s current working state during switching, ensuring uninterrupted operations

￮ Supports automatic scanning with a configurable cycle time of 5–255 seconds

5. Expansion and Compatibility

￮ Supports cascading expansion; a single 4-port unit can manage up to 9 servers

￮ Fully supports the DDC2B protocol, allowing detection of display device information even on unswitched channels

￮ Compatible with mainstream servers and industrial PCs from IBM, Dell, HP, Sun, Lenovo, Advantech, and Yanshang

￮ Supports multiple operating systems, including Windows, Linux, CentOS, Kylin, and Ningsi

6. Stable and Durable Construction

Constructed with high-strength, corrosion-resistant electrolytic steel plates and finished with a black high-temperature spray-painted speckled coating for robustness and wear resistance, making it suitable for industrial and data center environments; dual-power-supply design ensures more stable power delivery.
