Rack-Mountable CAT5 KVM Switch

| Product Features：

1. High-Definition Display Performance: With a bandwidth of 200 MHz, it supports resolutions up to 2048×1536, delivering true-to-life color reproduction and clear, stable images.

2. Comprehensive Keyboard and Mouse Compatibility: Supports dual USB ports for keyboard and mouse connections, and is compatible with mainstream optical mice, wireless mice, scroll mice, mechanical mice, and other devices.

3. Intelligent Switching Management

²  Automatically saves the keyboard’s current working state during switching, ensuring uninterrupted operations

²  Supports automatic scanning with a configurable cycle time of 5–255 seconds

4. Expansion and Compatibility Capabilities

² Supports cascading expansion; a single 8-port unit can manage up to 64 servers

² Fully supports the DDC2B protocol; display device information can be detected even on unswitched channels

² Compatible with mainstream servers and industrial PCs from IBM, Dell, HP, Sun, Lenovo, Advantech, and Yanshang

² Supports multiple operating systems, including Windows, Linux, CentOS, Kylin, and Ningsi

5. Stable and Reliable Design: Supports dual power inputs, wide-voltage auto-adaptation, low power consumption, and stable operation.
