Rack-Mountable 8-Port VGA Switch Over IP

| Product Features:

1. High-Definition Display Performance: With a bandwidth of 200 MHz, it supports resolutions up to 2048×1536, delivering true-to-life color reproduction and clear, stable images.

2. Comprehensive Keyboard and Mouse Compatibility: Supports connection of two USB keyboards and mice; compatible with mainstream optical mice, wireless mice, scroll mice, mechanical mice, and other devices.

3. Intelligent Switching Management

² Automatically saves the keyboard’s current working state during switching, ensuring uninterrupted operations

² Supports automatic scanning with a configurable cycle time of 5–255 seconds

4. Expansion and Compatibility Capabilities

² Supports cascading expansion; a single 8-port unit can manage up to 64 servers

² Fully supports the DDC2B protocol; display device information can be detected even on unswitched channels

² Compatible with mainstream servers and industrial PCs from IBM, Dell, HP, Sun, Lenovo, Advantech, and Yanshang

² Supports multiple operating systems, including Windows, Linux, CentOS, Kylin, and Ningsi

5. Stable and Reliable Design: Supports dual power inputs, wide-voltage auto-adaptation, low power consumption, and stable operation.

6. IP Remote Features

² Supports iMAC, PowerMAC, and Sun Microsystems devices via USB ports

² Supports external authentication servers and centralized management of user permissions

² Supports security logging, recording device switch events, user logins, logouts, network activity, and more

² Supports SYSLOG event logging, with direct forwarding to a SYSLOG server

² System logging supports the SNMP protocol

² Supports remote network and SSH protocol access

² Supports browser-based operation of the KVM and connection to its target servers

² Supports local control port configuration and remote browser-based KVM configuration

² Can be integrated with the SVC3000 management software for centralized control

² Supports multiple security authentication mechanisms: HikAuth, RSA, USBKEY, RADIUS, LDAP, TACACS+

² Advanced security mechanisms include password protection and advanced encryption technologies; 128-bit AES data encryption supports IP access control list filtering
