19-inch 8-Port VGA KVM with Dual Sliding Rails

▏Product Features：

■ All-in-one integrated design: Combines a 19-inch LED TFT LCD display, an ultra-slim silent keyboard, a high-sensitivity touchpad, and a switch into a single unit, saving rack space and simplifying cabling and maintenance.

■ Dual-Slide Rail Design: The display and keyboard/mouse can be pulled out independently. When the keyboard and touchpad are not in use, they can be pushed back into the rack, leaving only the LED display visible to facilitate server status monitoring by administrators.

■ Video Resolution: Features a 19-inch LED display with a 4:3 aspect ratio and optimal resolution of 1280 x 1024 at 60/75 Hz.

■ Convenient Installation Structure: The pull-out design features self-locking screen rails, with adjustable lengths to fit cabinets of varying depths. Installation and removal can be completed by a single person.

■ Comprehensive Keyboard and Mouse Compatibility: Supports connection of keyboards and mice via dual USB ports and is compatible with mainstream devices such as optical mice, wireless mice, scroll wheel mice, and mechanical mice.

■ Smart Switching Management

￮ Supports three switching methods: OSD menu, panel buttons, and custom hotkeys

￮ Automatically saves the keyboard’s current working state during switching, ensuring uninterrupted operations

￮ Supports automatic scanning with a configurable cycle time of 5–255 seconds

■ Expansion and Compatibility

￮ Supports cascading expansion; a single 8-port or 16-port unit can manage up to 256 servers

￮ Fully supports the DDC2B protocol; display device information can be detected even on unswitched channels

￮ Compatible with mainstream servers and industrial PCs from IBM, Dell, HP, Sun, Lenovo, Advantech, and Yanshang

￮ Supports multiple operating systems, including Windows, Linux, CentOS, Kylin, and Ningsi

■ Stable and Reliable Design: Supports dual power inputs, wide-voltage auto-adaptation, low power consumption, and stable operation.
