17.3-inch 4-Port VGA LED KVM Console

|Product Features:

1. All-in-One Integrated Design: Combines a 17.3-inch LED TFT LCD display, an ultra-slim silent keyboard, a high-sensitivity touchpad, and a switch into a single unit, saving rack space and simplifying cabling and maintenance.

2. High-Definition Display Performance: Supports resolutions up to 1920×1080 at 60 Hz, delivering true-to-life color reproduction and clear, stable images.

3. Convenient Installation Design: The self-locking pull-out rails can be flexibly adjusted to fit cabinets of varying depths, allowing a single person to complete installation and removal.

4. Comprehensive Keyboard and Mouse Compatibility: Supports dual USB ports for keyboard and mouse connections, compatible with mainstream optical mice, wireless mice, scroll mice, mechanical mice, and other devices.

5. Intelligent Switching Management

￮ Supports three switching methods: OSD menu, panel buttons, and customizable hotkeys

￮ Automatically saves the keyboard’s current working state during switching, ensuring uninterrupted operations

￮ Supports automatic scanning with a configurable cycle time of 5–255 seconds

6. Expansion and Compatibility

￮ Supports cascading expansion; a single 4-port unit can manage up to 9 servers

￮ Fully supports the DDC2B protocol; display device information can be detected even on unswitched channels

￮Compatible with mainstream servers and industrial PCs from IBM, Dell, HP, Sun, Lenovo, Advantech, and Yanshang

￮Supports multiple operating systems, including Windows, Linux, CentOS, Kylin, and Ningsi

7. Stable and Reliable Design: Supports dual power inputs, wide-voltage auto-adaptation, low power consumption, and stable operation.
